Garrett G57-2350 94mm

Description

Garrett G57-2350 Turbocharger 94mm

Garrett G Series G57 turbochargers feature the latest innovations in turbocharger technology. Advanced compressor and turbine aero offer a range of high horsepower performance boosting solutions for 3.0L – 12.0L engine platforms. 88mm, 94mm, 98mm, 102mm, 106mm compressor inducer sizes produce up to 2350 horsepower for today’s top drag race teams.

Garrett G57-2350 94mm Features:

• Supports up to 2000 horsepower
• 94mm compressor inducer | 133mm compressor exducer
• 118mm turbine inducer | 112mm turbine exducer
• 28% more turbine flow (compared to GTX)
• One-piece aluminum center housing
• 16mm dual ceramic ball bearing cartridge
• Outline interchangeable with GTX Gen II turbos
• Stainless Steel turbine kit sold individually. 1.09 A/R, 1.25 A/R, 1.41 A/R

Understanding the Name:
G57-2350
G designates 81 years of Garrett® heritage.
57 classifies the size of the frame. The remaining 3 digits identify the max horsepower rating of the turbocharger. (ie 2350)

If you’re unsure if this is the right turbo for your application and power goals, give us a call on 07 4602 3858!

About Garrett:

Garrett was born out of the passion of American founder, John Garrett, for aviation and engineering with the first product, an aircraft intercooler, released in the 1930’s. Turbochargers began rocketing in 1954 and into the auto industry in the 1990’s, when turbochargers went mainstream and global.

With more than 60 years of pioneering turbocharging systems, Garrett Motion is an automotive technology leader in turbochargers and related force induction systems. The company remains American base and is well regarded as one of the best in motorsport turbocharging technology.
